TECHNOLOGY

The GLS enamel is a critical component. It's not just any glass; it's a specially formulated borosilicate glass frit designed to have a coefficient of thermal expansion similar to that of the steel substrate.

This similarity minimizes stress at the glass-steel interface during temperature fluctuations, preventing cracking and spalling.

The enamel is also formulated to resist attack from a wide range of chemicals, including acids (except hydrofluoric acid), alkalis, and solvents. Different enamel formulations are available for specific applications, such as high-temperature service or exposure to particularly aggressive chemicals. The quality of the enamel is determined by factors such as its chemical composition, particle size distribution, and fusion characteristics.

Technical Specifications of Glass-Lined Steel Tanks

• Steel Substrate: Typically high-strength, low-carbon steel conforming to standards like ASTM A36 or equivalent.
• Glass Enamel: Borosilicate glass frit with specific chemical composition tailored to the application.
• Firing Temperature: Typically 800-900°C.
• Lining Thickness: Varies depending on application and design requirements.
• Impact Resistance: High, typically tested according to standards like EN 15158.
• Chemical Resistance: Excellent resistance to a wide range of chemicals, except hydrofluoric acid and concentrated hot alkaline solutions.
• Adhesion: Excellent adhesion between glass and steel due to chemical bonding.

• Glass lining prevents corrosion.
• Steel provides strength and flexibility.
• Surface resists impact and abrasion.
• Smooth surface ensures hygiene.
• Surface inhibits bacterial growth.
• Withstands wide temperature ranges.
• Designed for 35+ years of service.
• Requires minimal maintenance.
